Product Summary

Package 4DIP
Output Type DC
Number of Channels per Chip 1
Typical Forward Voltage 1.15 V
Maximum Collector Current 50 mA
Maximum Collector Emitter Voltage 80 V
Maximum Forward Voltage 1.3 V
Minimum Forward Voltage 1 V
Minimum Isolation Voltage 5000 Vrms
Maximum Collector Emitter Saturation Voltage 400 mV
Maximum Current Transfer Ratio @ Current 600 %
Maximum Input Current 60 mA
Maximum Power Dissipation 240 mW
Maximum Reverse Voltage 5 V
Operating Temperature -25 to 85 °C
Category Transistor and Phot ovoltaic Output Phot oCouplers
